Description
BANDSAW BUTCHERS 400
Thompson Senior 400 (Mk6 Supercut) Bandsaws are renowned for their High Quality Construction and Performance. They are designed to offer Superior Low Maintenance operation in processing plants, supermarkets and butcher shops. With quiet operations and Attractive appearance, they are “ideally” suited to a prominent position in shop fronts where they are exposed to the public.
Performance
The blade speed and efficient design of the Thompson Mk6 Supercut Butchers Bandsaw significantly improves cutting action.
- 1960m/min (6450ft/min)
- Cleaner cut, less bone dust on product
- Portion cutting is straight and accurate
- Blade does not wander
- Cuts through frozen product (blocks) effortlessly
- Increases cutting efficiency. (Greater production in less time)
Download Brochure Thompson 400 Butchers Bandsaw
Construction
The Thompson 400 Bandsaws are constructed from Heavy Duty Stainless Steel and the tables are made to withstand continuous pounding from ‘the product’.
The flywheels are made from mechanite and machined so that the teeth of the bandsaw blade do not contact the wheel surface. They are also designed to ensure the bandsaw blades cannot be dislodged from the wheel surface.
Operating
Start/Stop controls are located at the front of the machine and at eye level for quick and easy access.
The blade tension assembly automatically adjusts the blade to a factory preset tension.
The direct drive system eliminates the requirements for belt adjustments or replacement whilst ensuring positive and constant blade speed.
A powerful 4kW (5.5hp) motor ensures a continuous smooth cutting operation through all products fresh or frozen.
Cleaning
The high quality construction of the bandsaw ensures cleaning is expedient and thorough providing maximum hygiene.
Outstanding Features
- Blade Speed 1960m/min (6450 ft/min)
- Less bone dust on cut finished product
- Increased cutting efficiency
Safety- A priority not a compromise
The Thompson 400 Butchers Bandsaw offers safety features that maximise safety to the operator and other persons in close vicinity.
Work Place Safety is a necessity that should not be compromised.
Foot Controlled stop kick switches enable the bandsaw to be stopped safely when you, the operators hands are full.
Limit Switches on doors, blade guard and tilt up table ensure that during and after cleaning operations the bandsaw cannot be accidentally started, ie. if the doors and table are not closed or the blade guard not refitted.
Bandsaw Blades cannot be dislodged from purpose designed wheels again eliminating possibility of operator injury.
Brake
When the Bandsaw has been turned off the blade ceases to circulate (approximately 2 seconds), thereby eliminating the possibility of any accidents caused through blade run on.
Recommended Options
- Heavy duty stop kick switch
- Brake with 2 second stopping capability
- Door, table and blade guard sensors
Options
- Sliding table with stainless steel rollers
- Stainless steel flywheels
Senior Supercut Bandsaw Specifications
| Overall Height: | 1950mm | Blade Length: | 3290 mm (10′ 9.5″) |
| Table Size: | 890 x 930 mm | Blade Width: | 16mm |
| Cutting Height Maximum: | 440 mm | Blade Speed: | 1960 m/min (6450 ft/min) |
| Cutting Width: | 400 mm | Drive: | 4 kW (5.5hp) 4 pole (3 phase) |
| Floor Area (Door Closed): | 890 x 980 mm | Shipping Weight: | 310kg |
| Floor to Table: | 960 mm | Shipping Size: | 1020 x 1020 x 2100 mm |
| Power Supply (STD): | Recommended, 20A Circuit | Power Supply (with brake): | Recommended, 20A Circuit with curve 1 circuit breaker |
| Starting Current: | 45A | Run Current: | 3.4A |
Junior Supercut Bandsaw Specifications
| Overall Height: | 1780 mm | Blade Length: | 2815 mm (9′ 2.5″) |
| Table Size: | 750 x 800 mm | Blade Width: | 16mm |
| Cutting Height Maximum: | 400 mm | Blade Speed: | 1600 m/min (5300 ft/min) |
| Cutting Width: | 290 mm | Drive: | 2.2 kW (3hp) 4 pole (3 phase) |
| Floor Area (Door Closed): | 750 x 850 mm | Shipping Weight: | 260kg |
| Floor to Table: | 850 mm | Shipping Size: | 940 x 870 x 1750 mm |
| Power Supply (STD): | Recommended, 20A Circuit | Power Supply (with brake): | Recommended, 20A Circuit with curve 1 circuit breaker |
| Starting Current: | 22A | Run Current: | 2.1A |
Technical Data is to be used as a guide only and is subject to change without notice.
